M12 L-Coded Male Straight to Male Straight 4 POS 16 AWG Cable Assemblies | PUR Jacket

SKU:
54-5090001-01M
Write a Review

Maximize power delivery in industrial automation with M12 Power L-Code connectors, the PROFINET and PROFIBUS-approved standard for 24-volt DC power supply systems. Engineered to handle up to 16A per pin, these connectors deliver four times the power of standard M12 connectors while taking up 40% less space and supplying nearly 80% more power than traditional 7/8" high-power connectors.

Available in male and female configurations, these compact high-power cable assemblies support conductor sizes from 1.5mm² to 2.5mm², enabling efficient and space-saving designs for automation devices. Rated IP67, M12 L-Code connectors are dust-tight and capable of withstanding temporary water submersion up to 1 meter for 30 minutes, ensuring reliable operation in harsh environments.

Designed for DC power supplies with 63 V DC / 16 A, they are ideal for Fieldbus Ethernet I/O boxes, Ethernet-powered devices, network equipment, motors, drives, and valve control systems. With their rugged construction, high current capacity, and space-efficient design, Weltron M12 Power L-Code connectors deliver reliable, high-performance power distribution for today’s Industry 4.0 applications.
